Increase clearance between CAI and coil pack

Thread Tools

Search this Thread

  #1
Old 03-30-2011, 06:22 PM
Widespread Hummer's Avatar
Senior Member
Thread Starter
Join Date: Apr 2010
Location: The Mitten
Posts: 568
Default Increase clearance between CAI and coil pack

A number of people with the Spectre style intake have noted the lack of clearance between the coil pack and straight pipe. While looking at mine today, I looked a little farther down the system and found that by raising the forward "foot" of the filter box it lifts the CAI enough to take the pressure off the coil pack. I grabbed the nearest thing I could use as a wedge, which happened to be a golf tee, that you can see in the picture below. Tomorrow I am going to figure out a proper bushing to put under the rubber bushing in place on the mounting bracket. Hope this helps a few.

Attached Thumbnails Increase clearance between CAI and coil pack-img01851-20110330-1414.jpg
  #2
Old 03-30-2011, 06:31 PM
wfturner's Avatar
Senior Member
Join Date: Aug 2007
Location: Reno, NV
Posts: 989
Default

Originally Posted by Widespread Hummer
A number of people with the Spectre style intake have noted the lack of clearance between the coil pack and straight pipe. While looking at mine today, I looked a little farther down the system and found that by raising the forward "foot" of the filter box it lifts the CAI enough to take the pressure off the coil pack. I grabbed the nearest thing I could use as a wedge, which happened to be a golf tee, that you can see in the picture below. Tomorrow I am going to figure out a proper bushing to put under the rubber bushing in place on the mounting bracket. Hope this helps a few.
The DocOlds CAI has a small dimple to clear the coil pack. You may want to try that rather than move your air box, your choice.

  #3
Old 03-31-2011, 03:54 AM
Widespread Hummer's Avatar
Senior Member
Thread Starter
Join Date: Apr 2010
Location: The Mitten
Posts: 568
Default

Ideally, I should have just bought the AIRDOC but what I am dealing with is ABS, so I am only going to know I've gone too far once I've gone too far. I could patch if it went through but i'd rather not. What I did will only raise the box about 1/4" at the mounting point which translates to about 1 mm of movement of the CAI overall. I will have to make sure that doesn't cause a fitment issue at the rubber boots, but I think it should be fine. It really is only relieving the pressure on the coil pack from the straight tube to eliminate any rubbing.

  #4
Old 03-31-2011, 07:33 AM
wfturner's Avatar
Senior Member
Join Date: Aug 2007
Location: Reno, NV
Posts: 989
Default

Originally Posted by Widespread Hummer
Ideally, I should have just bought the AIRDOC but what I am dealing with is ABS, so I am only going to know I've gone too far once I've gone too far. I could patch if it went through but i'd rather not. What I did will only raise the box about 1/4" at the mounting point which translates to about 1 mm of movement of the CAI overall. I will have to make sure that doesn't cause a fitment issue at the rubber boots, but I think it should be fine. It really is only relieving the pressure on the coil pack from the straight tube to eliminate any rubbing.
If you have a heat gun you could dimple the ABS where the coil pack meets the tube.
Tricky but possible
Good luck, it sounds like you have it figured out
