I am getting ready to do a conversion from coil to rear air suspension. What I am looking for is either the rear pucks that the bottom of the air bags sit on top of. Maybe someone here has converted to coil springs and have these pucks and hardware just sitting around collecting dust.

Or maybe someone has the part number for them. I also need to know how they are fastened in place. I might have to make them out of billet aluminum if I cant get my hands on them. Thanks



I dont have exact dimensions but they are about 2.5" diameter and about 2" tall. Center hole with a single bolt holds it down. They are pretty basic plastic things and really are just to prevent the bottom of the air spring centered properly. This is what it looks like (only pic I have, sorry).

Puck part # is 15172565, bolt is M10X1.5X20 part #11515764

Look to this site to find part numbers and exploded part views.... https://nemigaparts.com/cat_spares/epc/hummer/



Thanks Mixman, exactly what I need, If I cant find tnem I will make a couple out of billet aluminum or delren on my lathe from your description. Much appreciated!

If there is anyone else who have converted from air to coils and have these I will buy them from you, just pm me!



Do you happen to have the Black Rubber mounts that the bottom of the air bag sits on?[

QUOTE=H2-SUT;408292]I am getting ready to do a conversion from coil to rear air suspension. What I am looking for is either the rear pucks that the bottom of the air bags sit on top of. Maybe someone here has converted to coil springs and have these pucks and hardware just sitting around collecting



Does anyone happen to have the black rubber mounts that the bottom of the airbag sits on? It’s number 19 in the diagram.
