just discovered mine is bent a bit. makes it hard to line up the bolt holes and puts tension on the bolts. was looking for another but i noticed theyre not the same. is this correct through all years? i have a 2010 h3t. thanks for any clarification.
-mike



i used a BFG on mine (BIG F***ING HAMMER)



wouldnt that be a BFH? not out of the question if i cant find one



BIG Fv¢KING GUN



Yes, the BFG only comes out when a bolt/nut is not cooperating.



Lol...



There is no difference in the splash shields for 2008+ H3s and 2009+ H3Ts.

However, 2006 and 07 H3s had a different impact panel/bumper, so those two years use a different splash shield. Since there are no 2006/07 H3Ts, those 06/07 H3 splash shields are different.

I am using an 06/07 Splash shield on my 09 H3 Alpha Off Road because I have a BA Winch Bumper that was designed to use the old version splash shields.



i see. appreciate the replies. man im looking at part no. 15848416 and it says its the one but the pic does not match what ive got so it makes me nervous to order. maybe just an outdated illustration? makes me wonder what the part number for the earlier version is and how do you order that one? or maybe you just dont, idk. what do yall think?

https://www.gmpartsdirect.com/oem-pa...hield-15848416



The 06/07 shield--> 15819134

Aftermarket Bumpers



ok so it says the no logo splash shield is part #15848416. which is the one i need. so a case of the illustration not being updated i hope. the h3 logo stamped one is part #15183779 and is marked no longer available. am i accurate? just want to be sure before i pull the trigger. thanks again for this clarification
